Yamaha MODX 7 Synthesizer

The MODX7 is the 76-key model in the company’s next-generation MODX series of affordable, high-performance synthesizers. Packing powerful technologies ported from Yamaha’s flagship Montage series, the MODX range features numerous state-of-the-art upgrades from their MOXF predecessors, including the AWM2 sample and synthesis engine fortified with eight times more waveforms, a powerful new 8-operator FM-X engine modernized for amazingly dynamic sonics and complex sound design, and Motion Control Synthesis for seamless integration and powerful control of both sound engines.

Packed with sophisticated features

In addition to the AWM2 and FM-X sound engines, the MODX7 is packed with sophisticated features (many handed down from Montage), including the Super Knob, which gives you simultaneous control over multiple parameters; the ability to send ten and return four audio channels plus 16 MIDI channels to/from your computer or iOS device over USB; Live Sets, which allow for Performance organization without copying, renaming, or changing order; and an A/D input that processes external audio sources through the MODX DSP. Also onboard is Yamaha’s Motion Sequences feature, which drives synth parameters via rhythmic control data you can intuitively interact with in real time; an Envelope Follower that lets you use internal or external audio as a synth parameter control source; and a Vocoder effect that re-creates the classic voice-synth sound. Four-part Seamless Sound Switching, the capacity for 27 simultaneous effects, an onboard 4-in/10-out audio interface, and 1GB of internal flash memory complete the feature set. The MODX7 gives you a powerful modern synthesizer, a potent controller with a multichannel USB audio/MIDI interface for extensive DAW and VST control, and an expressive 76-note LC synth-weighted keyboard to drive it all.

A powerful instrument that does it all

Keyboardists at Music Experience have long respected the top-notch sounds Yamaha loads into their keyboards, and the MODX7 is no exception. From stunningly realistic acoustic and electric pianos, guitars, basses, and drums to orchestral instruments to vintage and modern synth sounds, each patch is expertly crafted down to the finest detail, so you can call up any preset you like and never have to worry about tweaking your tone. When you’re in the mood to patch from scratch, however, the MODX7 provides a robust set of sound-sculpting tools for realizing your ultimate musical vision. Add to that a full complement of VCM-based effects and processors, and you’ll never run out of creative possibilities with the Yamaha MODX7. MODX7 boasts a broad selection of effects for both the internal sounds and for use with the A/D inputs, giving you access to the same effects found in Yamaha’s professional digital recording consoles. And MODX7 supports the use of 27 effects simultaneously, so you can polish your tracks to perfection.

What Yamaha Says…

For the keyboardist needing a wide range of expressive keyboard sounds, MODX is a synthesizer with ultra-realistic instrument and highly programmable synth sound. MODX works in any music performance or music creation situation.

Sound

Sound is the most important aspect of any instrument. The power of the MODX synthesis engine allows unlimited potential to create your own unique sound demanded by any artist. The MODX sound engine is based on the same technology powering the flagship MONTAGE: AWM2 (Advanced Wave Memory 2) sample and synthesis engine and a pure FM-X (Frequency Modulation) synthesizer modernized for amazing sound playback and complex sound design.

AWM2

Only found in Yamaha music synthesizers, the AWM2 engine offers much more than just sample playback. Each of the 16 AWM2 parts feature eight fully-programmable synthesizers with a filter (18 different types!,) amplitude, pitch and filter envelope generators, nine LFOs, 3-band EQ and a dedicated dual insert effect with Virtual Circuitry Modeling.

FM-X

FM-X is an amazingly sophisticated pure synthesizer engine capable of producing classic ‘80s or cutting-edge, EDM sound with incredible dynamic range, power and fidelity. MODX features an 8-operator FM architecture and 64-note polyphony, allowing for a massive array of sound design options.

192-Note Total Polyphony

MODX features 128-note stereo AWM2 polyphony and 64-notes of FM-X polyphony. Due to the unique architecture of MODX and MONTAGE, this polyphony is always available without latency or compromising other features.

SSS Seamless Sound Switching

Seamless Sound Switching (SSS) lets you change performances seamlessly without any cut-off in envelope or effects. This is perfect for live performances where you end one song and start another without stopping.

Integratedflash

MODX includes 1 GB of non-volatile user flash memory with high speed reading/writing for your own custom samples or synth libraries from yamahamusicsoft.com.

Effects

From high definition reverbs to incredibly detailed Virtual Circuit Modeling (VCM) effects, MODX is loaded with DSP innovation, power and, most importantly, sound quality. Use effects like Beat Repeat, Vinyl Break or Bit Crusher to get EDM sound. The Spiralizer effect creates the auditory illusion of a tone continually rising or falling in pitch without getting higher or lower. You can even add a compressor with sidechain for a modern “ducking” effect. Or go retro with vintage effects like Analog Delay, VCM Phaser or a variety of Amp Simulators. Piano players will appreciate piano-focused effects like Damper Resonance for a super-realistic piano experience and the HD reverbs that let you put yourself in any performance space.

A/D Input

Coupled with two A/D inputs, MODX is a perfect centerpiece for any professional recording studio or live computer rig.

Sidechain

Automatically control the dynamic behavior of one part from another. Sidechain is very popular in modern dance music where a pad or other sustain part is “keyed” to the kick drum. When the kick drum plays, it ducks down the sustained part creating a “pumping” rhythmic effect.

Multi-Channel USB Audio Interface

As expected for modern computer-based music production, MODX features a professional 4-in/10-out, multi-channel USB audio interface. A single-cable connection replaces the need for an external audio interface. iOS compatible.

Super Knob

The Super Knob allows simultaneous control of up to 128 parameters in a single Performance. This means you can control nearly anything from mix functions like volume, pan and effect sends to detailed synth parameters like filters, LFOs and Operators. That’ s 128 parameters…SIMULTANEOUSLY! The Super Knob can even be assigned to a second FC7 foot controller making it easy to manipulate the sound when playing with both hands.

Motion Sequences

Motion Sequences are tempo-synchronized, completely customizable control sequences that can be assigned to virtually any synthesizer parameter and provide incredible new ways of creating sound. Motion Sequences also have dedicated controls on the front panel making it easy to manipulate and change in real-time, providing incredible interactivity and expression.

Envelope Follower

The Envelope Follower converts audio into a control source for control of virtually any synthesizer parameter. For example, a drum loop could drive effects parameters for a cool rhythm or a vocal recording could control multiple parameters for a “talking” synthesizer. The audio can even be a “live” source through the A/D input.

Audio Beat Sync

ABS (Audio Beat Sync) detects the beat of and external device like an electronic drum kit, drum machine or audio player plugged into the A/D input and synchronizes the MODX Arpeggiator, Motion Sequencer or Songs to the tempo of the external input. The MODX synthesizer “listens” to live music and plays in time.

Cubase AI Bundle

MODX is bundled with Cubase AI, Steinberg’s professional music production application that offers integrated recording and editing.

Mobility

Designed for musicians on the go, MODX is compact, lightweight and mobile.

Lightweight

The MODX6 weighs in at 14.6 lbs, the MODX7 at 16.3 lbs and the 88-note weighted Graded Hammer Action MODX8 comes in at a svelte 30.4 lbs.

MODX Connect

MODX Connect is a convenient tool which lets you transfer data between your computer and the MODX. Song data created on the MODX can be transferred to your computer and the Performance data edited on the MODX can be saved as a file (.X7B) on the computer. MODX Connect, based on Steinberg’s VST3 technology, works as a VST3 plug-in with the Cubase series. The MODX Connect also works as the same way as other VST instrument software, allowing you to save the edited settings of the MODX, or use them for another project. MODX Connect also works as an AU plug-in. For AU compatible DAW software, refer to the separate Release Notes. It can also be used as standalone software.

Soundmondo

Create your sound, inspire and be inspired with Soundmondo – a social sound-sharing app  for creative music-makers. Soundmondo now features MONTAGE and MODX music synthesizer Performance compatibility. For music-makers interested in expressing their personality through sound, Soundmondo is a social sound-sharing community for creating, sharing and exploring synthesizer sounds. Whether you’re a seasoned sound designer or just beginning your synth exploration, Soundmondo has an intuitive workflow making it easy to use – and best of all, it’s free!

FM Converter for MONTAGE and MOD

The FM Converter Web App provide a mechanism for MONTAGE owners to convert their legacy FM libraries and onboard legacy product content to MONTAGE native User File Format that also can be loaded to MODX.

Compatibility with the MONTAGE

The MODX uses the same technology powering the flagship MONTAGE. User and Library files can be loaded to MODX.

Compatibility with the MOTIF XF/MOTIF XS/MOXF

As same as MONTAGE, MODX is fully compatible with the Yamaha MOTIF XF/MOXF synthesizer. MOTIF XF/MOXF libraried, third-party patch libraries, user voices, user performances, user arpeggios and user waveforms from MOTIF XF/MOTIF XS/MOXF files can be imported.
