Wharfedale Pro VERSADRIVE SC-48 FIR Signal Processor
Original price was: R23,995.R20,271Current price is: R20,271.
Availability: Only 1 left in stock
Wharfedale Pro VERSADRIVE SC-48 FIR Signal Processor
Think Dif FIR ently
The Wharfedale Pro VERSADRIVE SC-48 FIR Signal Processor is a 4-in / 8-out signal processor from our VERSADRIVE Series — engineered to deliver advanced tuning, routing and FIR-based optimisation for large-scale live and installation systems.
Equipped with high-resolution 24-bit / 96 kHz AD/DA converters, SC-48 FIR combines powerful DSP processing with FIR filtering technology, enabling independent control over magnitude and phase for more precise equalisation, improved frequency response and enhanced power consistency across the system.
With four input channels and eight fully routable outputs, it offers comprehensive matrix flexibility for complex PA configurations. Each output includes RMS compressors and peak limiters, ensuring robust loudspeaker protection and stable long-term performance.
Connectivity options include USB, RS232, RS485 and Ethernet (RJ45), providing full remote PC control via the included software — ideal for both touring engineers and fixed venue installations. AES digital inputs ensure seamless integration with digital audio systems, while password protection secures settings in permanent installs.
With FIR precision, comprehensive preset library, extensive routing capabilities and advanced protection tools, VERSADRIVE SC-48 FIR sets the standard for high-end system control and optimisation.
| Specification | Value |
|---|---|
| Inputs | 4 |
| Outputs | 8 |
| Input Type | USB / RS232 and RS485 |
| Controller Data Connection | Dante® |
| Input Connections | XLR |
| Output Connections | XLR |
| Input Impedance | Balanced 500 KΩ, Unbalanced <500 KΩ |
| Input Effects | Gain, Mute, Link, High-pass filter, Low-pass filter, Noise Gate, 8-band parametric EQ, 31 band graphic EQ, Phase, Delay |
| Output Effects | Crossover, 5-band parametric EQ, Gain, Mute, Compressor / Limiter, Phase, Delay, Linking |
| Max Input Level | +18 dBu |
| Max Output Level | +20 dBu |
| Frequency Response | 20 Hz-20 KHz，-0.3 dBu |
| FIR | Yes |
| SNR | >115 dBu |
| THD+N | <0.005 at 1 KHz (0 dBu) |
| Digital Processing | 24-bit sigma-delta，96 KHz sampling rate |
| Software Included | Yes |
| User Presets | Yes |
| RS232 Port | Yes |
| Impedance | Balanced 500 KΩ, Unbalanced <500 KΩ |
| Crosstalk | <100 dB below full scale |
| Display Type | 20 × 2 LCD Display |
| Password Protected | Yes |
| Included Accessory | Power Cable, User Manual |
| Unpacked – Height (mm) | 45 |
| Unpacked – Width Front (mm) | 480 |
| Unpacked – Width Rear (mm) | 480 |
| Unpacked – Depth (mm) | 245 |
| Weight – Nett (kg) | 2.88 |
