Wharfedale Pro T-SUB-AX12B Active Subwoofer

Wharfedale Pro T-SUB-AX12B Active Subwoofer

Original price was: R11,995.Current price is: R9,716.

Availability: In stock

SKU WHAR-T SUB AX12 B Categories Active Speakers, AV, Loudspeakers, WHARFEDALE

Wharfedale Pro T-SUB-AX12B Active Subwoofer

Versatile 12″ active subwoofer. Everyone loves BASS.

The Wharfedale Pro T-SUB-AX12B Active Subwoofer is a 12″ active subwoofer from our T-SUB-AX Series — delivering powerful, punchy low-end reinforcement in a compact, durable design.

Powered by a convection-cooled Class D amplifier, it delivers 500 W continuous and 1000 W peak output through a custom Wharfedale Pro quad-layer 12″ driver with a 2.0″ voice coil. The adjustable low-pass filter allows quick system tuning, making it an ideal companion for active tops such as the Tourus, Titan and Typhon series.

Constructed from premium birch plywood and finished in our rugged polyurea Tough-Tone paint, the T-SUB-AX12B features an illuminated front logo, integrated handles and a 35 mm pole socket for flexible setup. Compact, reliable and ready to perform — it’s small in size but huge in sound.

Specification	Value
Active or Passive	Active
System Type	Subwoofer
Configuration	Bass-reflex
System Continuous Power	500 W
System Peak Power	1000 W
Max SPL @ 1m	130 dB (Half Space)
Freq Range (-10 dB)	45 Hz – 250 Hz
Freq Response (+/-3 dB)	50 Hz – 200 Hz
IP Certification	None
Driver Brand	Wharfedale Pro
LF Driver Size	12″
LF Voice Coil Size	Quad Layer 2
LF Rated Impedance	4 Ω
LF Power (RE:AES2-2012)	250 W
Input Connector	2 x XLR
Enclosure Material	Birch Plywood
Grille Material and Finish	Steel Black
Finish	Black Tough-Tone
Handles	2
Deployment	Ground
Pole Mount	35 mm
Sensitivity 2.83v / 1m	n/a dB
System Rated Impedance	n/a
Crossover Frequency	LPF 80-200 Hz (adjustable)
Recommended HPF = BW 18 dB/OCT.	45 Hz
Amplifier design	Class D
Active loudspeaker Input Impedance	47 KΩ Balanced
Link Connector	2 x pin XLR
Input sensitivity	-10 dBu
Max input level	5 V
DSP Controls	Polarity switch 0° / 180°, LPF 80-200 Hz (adjustable)
Main Power	100 V-120 V and 200 V-240 V
Power Supply	SMPS
Included Accessory	Quick Start Guide, AC Cable
Unpacked – Height (mm)	378
Unpacked – Width Front (mm)	493
Unpacked – Width Rear (mm)	493
Unpacked – Depth (mm)	468
Packed – Height (mm)	475
Packed – Width Front (mm)	563
Packed – Width Rear (mm)	563
Packed – Depth (mm)	538
Weight – Nett (kg)	21
Weight – Gross (kg)	25.5
